衬氟角式截止阀J44F46

 ■主要零件及材料  Main parts and materials

零件名称
part name
材料material
  阀体body、
阀盖cover
铸钢cast steel、不锈钢 stainless steel、内衬liningF4、F46
阀瓣disc优碳钢 excellent carbon steel、不锈钢 stainless steel、衬liningF4、F46
阀杆
Stem
2Cr13、不锈钢 stainless steel
填料packingPTFE(F4)聚四氯乙烯
阀杆螺母
stem nut
2HMN58-2-2
手轮
handwheel
HT200

  衬氟直角截止阀标准PTFE-Lined right angle globe valve standard


技术规范
 technical specification
设计标准
Design criteria
GB12233
结构长度structure lengthGB12221
法兰标准
flange standard

JB/T79-94
GB9113.1-26
检验试验Inspection testGB/T9092-99
驱动方式
Drive mode
手动manual、电动electric、气动pneumatic



公称通径
Nominal diameter
PN1.6(MPa)主要外形尺寸和连接尺寸main form and connection size重量weight
DNLDD1D2fbZ-φdD0H1H2Kg
15909565433144-φ141001701854.5
209510575503144-φ141002002204.5
2510011585603164-φ141202052305.5
32105135100683184-φ181402302608
40115145110803184-φ1816025529210
501251601251003204-φ1818027031512
651451801451153.5204-φ1820033539018
801551951601303.5228-φ1824029546524
1001752151801504248-φ1828042050629
1252002452101804268-φ1832049060046
1502252802402104288-φ2336052067067
20027533529526053212-φ18400590740100
25032540535531953612-φ26450660840150
30037546041037064012-φ26500710900250

截止阀J44.JPG截止阀J44 - 副本.JPG
